Reliable Pneumatic Butterfly Valve for Automated Flow Control
Parth Engineering offers Pneumatic Butterfly Valves designed for industrial and process applications where reliable flow control, pipeline isolation and pneumatic automation are required. These valves combine the compact and practical design of a butterfly valve with pneumatic actuation, allowing the valve to be operated using compressed air.
Pneumatic Butterfly Valves are suitable for applications where manual operation is not preferred or where valves need to be integrated with an automated process control system. Pneumatic operation can provide convenient remote operation and controlled opening and closing of the valve according to the requirements of the process.
Parth Engineering focuses on providing industrial valve solutions with a quality-oriented approach, experienced professionals and suitable manufacturing technology. Our Pneumatic Butterfly Valves can be selected according to valve size, process media, operating pressure, temperature, connection arrangement and actuation requirements.
What Is a Pneumatic Butterfly Valve?
A Pneumatic Butterfly Valve is a butterfly valve operated using a pneumatic actuator. Instead of manually rotating the valve, compressed air is supplied to the actuator to move the valve between its required operating positions.
The butterfly valve uses a rotating disc positioned inside the flow passage. When the disc is rotated to the open position, the process media can flow through the pipeline. When the disc moves toward the closed position, the flow is restricted or isolated.
The pneumatic actuator provides an automated method of operating the valve. This makes Pneumatic Butterfly Valves suitable for industrial processes where frequent valve operation, remote control or integration with an automated control system is required.
The appropriate valve and actuator configuration should be selected according to the process conditions and control requirements.
Pneumatic Butterfly Valve Design
A Pneumatic Butterfly Valve generally consists of a butterfly valve body, disc, stem, sealing arrangement and pneumatic actuator. The actuator converts pneumatic energy into mechanical movement to rotate the valve disc.
Depending on the selected actuator configuration, the valve can be arranged for suitable automated opening and closing operations. The actuator can also be connected to an appropriate control system for process automation.
The compact butterfly valve design allows the pneumatic valve to provide an efficient flow control arrangement while the pneumatic actuator enables convenient operation.
The exact valve construction, material and actuator specifications should be selected according to the intended application.
Key Features of Pneumatic Butterfly Valve
Parth Engineering Pneumatic Butterfly Valves are designed around practical industrial automation and flow control requirements.
Operated using compressed air for automated valve movement.
Suitable for applications where automated opening, closing or isolation is required.
Can be integrated into suitable control systems for remote valve operation.
The butterfly valve configuration provides a practical solution where installation space is an important consideration.
Pneumatic actuation can provide convenient and responsive valve operation in suitable applications.
Suitable for various industrial and process pipeline applications.
Single-acting or double-acting pneumatic arrangements can be considered according to application requirements.
Designed for dependable operation when correctly selected and used within suitable operating conditions.
Technical Specifications
The applicable Pneumatic Butterfly Valve configuration should be selected according to the required application and operating conditions.
| Parameter | Specification |
|---|---|
| Actuation | Single Acting / Double Acting |
| Operating Pressure | 2.5 bar to 8 bar |
| Size Range | 19 mm to 102 mm |
| Maximum Pressure | 10 bar |
| Operating Temperature | -10°C to 180°C |
| Connection | Tri-Clamp |
| Suitable Media | Water, Milk, Beverages and other compatible media |
The exact technical specification should be confirmed according to the selected valve size, actuator, material, process media, pressure, temperature and connection requirements.
Applications of Pneumatic Butterfly Valve
Pneumatic Butterfly Valves can be used in suitable industrial and process applications where automated flow control or isolation is required.
Industries Served
Pneumatic Butterfly Valves can support suitable automation and flow control requirements across different industrial sectors.
Filter housings and filtration consumables for efficient and dependable process filtration.
Filter bags and liquid filtration products for industrial processing applications.
Gas filtration products for effective filtration and process control.
Butterfly valves for reliable industrial flow regulation and isolation.
Delrin rods and sheets for industrial fabrication and engineering requirements.
Product configurations and solutions based on specific industrial application requirements.
Single Acting Pneumatic Butterfly Valve
A Single Acting Pneumatic Butterfly Valve uses compressed air for one direction of actuator movement, while the return movement is supported by a spring mechanism.
This configuration can be considered for suitable applications where a defined return position is required when pneumatic air supply is removed.
Single-acting operation can be useful in process systems where the valve needs to move toward a predetermined position under specific operating conditions.
The appropriate spring configuration and actuator size should be selected according to the valve and application requirements.
Advantages of Pneumatic Butterfly Valve
Pneumatic Butterfly Valves provide several practical advantages for suitable automated industrial applications.
One important advantage is the ability to operate the valve without requiring direct manual intervention. The pneumatic actuator can be controlled through a suitable process control system, making it useful for automated installations.
Pneumatic operation can also be beneficial in applications where valves need to be operated frequently. The actuator provides a convenient method of moving the butterfly disc between operating positions.
The compact butterfly valve configuration can help maintain a practical installation arrangement while providing the required flow control function.
Pneumatic Butterfly Valves can also be considered where remote operation and process automation are important requirements.
Pneumatic Butterfly Valve for Process Automation
Automation is an important requirement in many modern industrial process systems. Pneumatic Butterfly Valves provide a practical method of incorporating butterfly valves into automated pipeline systems.
The pneumatic actuator can receive signals from an appropriate control system and operate the valve according to the process requirement. This can help reduce the need for manual operation, particularly where valves are installed at locations that are difficult to access or where repeated operation is required.
The actuator and valve combination should be selected according to the required operating frequency, air pressure, valve size and process conditions.
Why Choose Parth Engineering Pneumatic Butterfly Valve?
Parth Engineering has been serving industrial requirements since 2007 and is engaged in the manufacturing, supply and servicing of industrial valves and filtration products.
Our approach focuses on quality products, experienced professionals, suitable manufacturing technology and customer requirements. We source quality raw materials from reliable industry suppliers and follow defined quality checks during the manufacturing process.
Our experienced professionals support manufacturing and product-related activities, while our infrastructure supports procurement, production, quality control and sales operations.
We understand that pneumatic valve requirements can vary depending on the process and automation system. Therefore, customers can share details such as valve size, process media, pressure, temperature, air supply and actuator requirements with our team.
Quality-Focused Manufacturing
Quality is an important part of Parth Engineering’s manufacturing approach.
We focus on quality raw materials sourced from reliable industry suppliers and use skilled professionals and suitable manufacturing technology during production. Finished products are checked against defined quality parameters to help maintain consistent product quality.
Our manufacturing infrastructure and experienced team support our objective of providing industrial valve and filtration solutions according to customer requirements.
We also focus on professional service, customer satisfaction and timely support throughout the product enquiry and supply process.
How to Select the Right Pneumatic Butterfly Valve
Selecting the right Pneumatic Butterfly Valve requires consideration of both the valve and pneumatic actuator.
Important factors include:
- Required valve size
- Pipeline size
- Process media
- Operating pressure
- Maximum pressure
- Operating temperature
- Connection arrangement
- Manual or pneumatic operation
- Single-acting or double-acting requirement
- Installation space
- Application conditions
- Maintenance requirements
Request a Quote for Pneumatic Butterfly Valve
Looking for a Pneumatic Butterfly Valve for your industrial or process automation application? Share your required valve size, process media, operating pressure, operating temperature, connection type, pneumatic air pressure and actuator requirement with Parth Engineering.
Our team can help you explore a suitable Pneumatic Butterfly Valve configuration based on your specific industrial and process requirements.
